Trust Is a Rendering Problem
Designing provenance into retrieval-augmented systems
A model that is right 95 percent of the time, with no way to tell which 5 percent is wrong, is less useful than one that is right 80 percent of the time and admits when it is unsure. Being accurate is an engineering goal. Knowing when to doubt itself is a design one.
Retrieval-augmented generation, or RAG, solved the obvious problem. RAG just means the AI looks things up first, then answers. Instead of asking the model to recall a fact from memory, you fetch it from a real source and hand it over. The AI makes things up far less often. Engineering calls it a win and moves on.
But the user is left knowing exactly as little as before. They read smooth, confident text with no way to tell where a sentence came from. Was it the fetched document, the model's own memory, or the join where the two were stitched together? Smooth writing is not proof. We have just moved the problem from the model to the screen.
Why citation is hard, not just important
A model can write a perfect citation for a claim it never looked up. This is the part that catches teams out. The citation is generated the same way as the prose: a plausible source name, sometimes a plausible URL, predicted token by token because it fits the pattern of a citation. It looks retrieved. It was invented.
The numbers here are not reassuring. In 2023 a Stanford team audited four generative search engines, including Bing Chat and Perplexity, by hand. On average, only 51.5 percent of generated sentences were fully supported by their citations, and only 74.5 percent of citations actually supported the sentence they were attached to. So roughly a quarter of the citations pointed at something that did not back the claim. The systems looked trustworthy. That was the problem.
So the interface has one job before any other: keep retrieved and generated apart, and never let them look the same. Most products fail this. They render a model-written citation in the same blue as a real retrieved one, and the user cannot tell which is which. The fix is structural, not visual. The model is never allowed to write a citation string. Only the retrieval layer, the part that actually fetched a document, can attach a source. If a sentence has no fetched source behind it, it is unsupported, and it must look unsupported. The screen shows what was retrieved, not what was written to look retrieved.
The failure is not hypothetical. In 2023 a New York lawyer filed a court brief full of case citations that ChatGPT had invented, complete with fabricated quotes and fictitious airlines. A judge fined him and his firm 5,000 dollars. The model had done exactly what models do: produced text shaped like citations, because that is what the pattern called for. A reader who could not tell generated from retrieved took it at face value. Your users do the same, only faster and far more often.
The distinction has to be built in early, because you cannot recover it later. Once the model has written a sentence, no inspection tells you for certain whether it came from the fetched document or from the model's memory. They are the same words on the page. The only reliable answer is to track it at the source. The retrieval step tags each fact with the document it came from, the model carries those tags through, and any sentence that arrives without one is marked unsupported by default. Trust you add after the fact is a guess. Trust you record at the moment of retrieval is a fact.
Three levels of attribution
Most products ship level one and call it citations. The gap between one and three is where trust actually lives. Think of a recipe that tells you which shop each ingredient came from. Good attribution does that for an answer.
- 01Document level. A list of links under the answer. Cheap, common, and almost useless. It proves the system read something, not that this sentence came from it.
- 02Passage level. Each claim points to an exact passage in an exact source. Hover or tap the claim and you see the exact text. This is the lowest bar for anything a professional will act on.
- 03Conflict level. The system tells you when its sources disagree, and shows you both. This is where an AI tool stops acting like an oracle and starts acting like a research tool.
- Smooth text in one confident voice
- No way to see which claim came from where
- You must redo the search to check it
- Sources that disagree stay hidden
- Each claim linked to a source passage
- Hover or tap reveals the exact passage
- Checking takes seconds, not minutes
- Sources that disagree are shown, not blended
Users need to be able to verify AI output, and the interface must make verification cheaper than doing the task manually. Otherwise the AI is a liability.
The cost-of-checking test
Here is the only number I care about when reviewing an AI feature. Measure how long it takes a user to confirm an answer is right. If checking takes longer than just doing the work, the feature is a loss, no matter how good the demo looked.
Look at the second bar. An answer with no sources is often slower than no answer at all. The user now has to work out the search that would have found the source. You added a step and called it automation.
Showing doubt without wrecking the page
The naive move is a percentage. Ninety-two percent sure. It fails for two reasons, and both matter. First, users read 92 percent as the chance the answer is correct. It is not that. It is the model's own guess about itself, which is a different thing. Second, that guess is usually wrong.
Models are badly calibrated, and this is measured, not folklore. Modern networks are systematically overconfident: a batch of answers a model rates 90 percent sure is right well under 90 percent of the time. When you ask a chat model to state its confidence in words, the same gap shows up. It clusters its bets high and rarely says it is unsure, even when it should be. A number that does not track reality is worse than no number, because it looks like data.
So a good confidence signal is not a number. It is a small, honest ranking, shown visually, and tied to what is at stake. It should say where a claim sits, backed or unbacked or contested, and it should open into the evidence when tapped. It should never collapse three different questions, is there a source, how fresh is it, how sure is the model, into one figure that hides all three. Rank, do not score. Point at evidence, do not assert a percentage.
There is a simple test for whether a signal is honest. Can the user act on it, and does acting on it lead to evidence rather than another opinion. A backed claim opens to the exact passage that supports it. An unbacked one opens to a plain admission that the system is working from memory here, so check before you rely on it. A contested one opens to both sides. Every state resolves into something the reader can look at, not a mood the interface is in. The moment a signal cannot be opened into evidence, it is decoration, and decoration that looks like certainty is worse than silence.
- Backed claims look normal. Full contrast, no fuss. This is the default, and it should feel like reading, not like an audit.
- Unbacked bits fade back: lower contrast, a thin underline, and a way to ask why. Never a red warning. You are flagging doubt, not an error.
- Sources that disagree get a real UI element: both claims side by side, both sources named, no blending. The model must never average two clashing documents into one confident sentence.
- Old sources show their age. A right answer from a document replaced eight months ago is a wrong answer with good manners.
| Support level | How it looks | What you can do |
|---|---|---|
| Backed | Full contrast, reads as normal text | Hover shows the exact source passage |
| Reasoned | Normal weight, a small join mark | Shows the sources it reasoned across |
| Unbacked | Lower contrast, thin underline | Tap to ask why, never a red alert |
| Conflict | Both claims shown side by side | Each source named, no blending |
| Old | An age badge on the citation | Warns when the source is out of date |
type Span = {
text: string
support:
| { kind: "grounded"; sourceId: string; offset: [number, number] }
| { kind: "inferred"; from: string[] } // reasoned across sources
| { kind: "unsupported" } // model memory only
| { kind: "conflict"; sources: string[] }
}
// The renderer never receives a plain string.
// If a span cannot declare its support, it does not render.
function Answer({ spans }: { spans: Span[] }) { /* ... */ }Why this is a design problem and not an ML one
No model upgrade removes the need to show where the answer came from. Even a perfectly accurate system on your company's documents needs to show its work. The user's question is rarely just what is true. It is true according to whom, as of when, and does anyone here disagree. Those are editorial questions. They have always been design questions.
This is why I think these source patterns will end up in design systems, the way focus states and empty states did. A citation is not a link. It is a component with states, thresholds, keyboard behaviour, and a clear story for when the source is deleted, locked, or wrong.
Conflict is the case that separates a research tool from an oracle, and it is the one most systems bury. When two sources disagree, the smooth move is to average them into one confident sentence. That is the most dangerous thing the interface can do, because it manufactures a certainty neither source supports. Show both. Name both. Let the reader see the disagreement and decide, the way they would with two colleagues who remember a meeting differently. An interface that hides conflict is not being helpful. It is quietly picking a side.
What to do on Monday
Pick one AI answer in your product and time it. Sit with a real user, give them a real answer, and measure how long it takes them to satisfy themselves it is true. That number is the feature's real score, not the accuracy on a slide. Then make one change. Render any sentence with no retrieved source in a visibly weaker style, and put the exact source passage one tap away on the rest. Do not touch the model. You will usually cut the checking time more with that one rendering change than with a bigger model, because you were never fighting accuracy. You were fighting the cost of trust.
